Hydraulic Hose Crimping Machine

120D

Cr40 forge steel made H.C, more than 6 months aging treatment

2mm thick hardened layer

Pipeless hydraulic valve-block connection

Stable pressure conduction fits in any workshop

Semi-auto mode achieves accurate crimping

Fully-auto mode enables batch crimping

Inquire Now

Hose Crimping

This hydraulic hose crimping machine, also known as hose swager, is heavy-duty industrial equipment for hydraulic hose assembly. It is used to crimp metal fittings onto rubber hydraulic hoses to form leak-proof hose assemblies. With powerful and adjustable crimping force, it delivers uniform, reliable crimp results for different hose diameters. Widely adopted in hydraulic system workshops, engineering machinery, mining and fluid transmission industries for batch hose production.

Model	Hydraulic Hose Crimping Machine
H.C. Material	3 - 80 mm
Conductor cross-section	Forge Steel ( Cr40 )
Max.Hydraulic hose	2”, 4SP ( ID 51MM )
Max opening	+ 25 mm
Crimp force	200 T
OEM	Yes
Die sets	10 sets
Open cycle	4.5 seconds
Open without dies	118 mm
Accessible diameter	118 mm
Master die length	80 mm
System pressure	31.5 MPa
Control	Automatic / Semi-automatic
Power supply	AC 110 - 480V
Rated power	4 KW
Noise level	65dB(A)
Dimensions	L 600 x W 480 x H 690 mm
Weight	220 KG
