JCW-325
Automatically clamp the wire end
Twist single wires into a twisted pair
LCD display, English menu, fully programmable
Data library saves 99 twisting programs
High-speed, 300 - 7500 RPM
Max 20 sections twisting
Twisting direction and speed are adjustable for each section
Automatic Wire Twister
| Model | JCW-325 Automatic Wire Twisting Machine |
| Function | Short wire, twist various single wires into pairs, twist cycles, twist speed, data library, multi-section twisting |
| Wire clamp method | Automatic |
| Twisting speed | 300 - 7500 RPM |
| Twisting cycles | 0.5 - 9999.9 |
| Wire diameter | 4 x 1.2 mm max |
| Data library | 99 wire programs |
| Multi-section twisting | 20 sections max |
| Power supply | AC 110 - 220 V ± 10%, 50 / 60 Hz |
| Dimensions | L 220 x W 240 x H 290 mm |
| Weight | 15 KG |
| CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
