JCW-C04B Automatic Soft PVC Tube Cutting Machine

Straight cut, precise feeding, 12mm diameter


Unique tube guider, specialist cutting machine

The JCW-C04B automatic tube cutter uses a one-piece guide tube, the material passes through it, and each cut is executed accurately and vertically, straight cut is our promise.


This electric cutting machine can cut PA, PE, PU, PTFE, rubber, and silicon tubes. The JCW-C04B cutting machine uses high torque stepper motors and subdivision drives, this perfect combination ensures high cutting speed, meanwhile, the machine is extremely quiet.


We supply metal or PU-coated rollers for selection, both offer precise feeding length as well as all-around protection to the materials. The clamping diameter can be changed easily by turning a wheel.


The JCW-C04B automatic tube cutting machine can be used as a stand-alone machine or it can be integrated into a processing line.


Smart and simple

The JCW-C04B automatic tube cutting machine is a fully programmable model. The feeding speed, cutting speed, batch quantity, total quantity, etc. can be input in seconds via touchscreen. The input value will be saved automatically. This cutting machine is capable to save 100 programs.  No need for any training, anyone can use it well.

ModelJCW-C04B Automatic Soft PVC Tube Cutting Machine
FunctionCutting speed, feeding speed, save the program, calibrate the cutting length
Raw material

PA, PE, PU, PTFE, rubber, and silicon tubes

Round material diameter12 mm
Guide tubeI.D 6 / 9 / 11 / 13 mm
Cutting length ( L )0.1 - 99999 mm
Cutting length increment0.1 mm
Cutting length tolerance0.002 x L
Production rate5000 - 15000 pcs /h
Data library100 programs
OEMYes
Power supplyAC 110 - 220V + 10 %, 50 / 60 Hz
DimensionsL 460 x W 470 x H 350 mm
Weight33 KG
CE-Conformity

Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
