Fully electric desktop automotive cable tie machine

JCW-T08

Inquire Now

Automotive cable tie machine

The JCW-T08 fully electric desktop cable tie machine is designed specifically for custom cable ties. It can be equipped with pneumatic cylinders to accommodate special functions and requirements.

This cable tie machine automatically punches, tightens, trims, and recycles scrap after manually placing the tie and pressing a pedal. The built-in positioning device further improves product yield and uniformity.

A single cycle takes less than 1.5 seconds, significantly reducing manual workload and fatigue while improving production efficiency, making it a perfect alternative to manual cable tie tools.

The tail length and loop size can be adjusted via the touchscreen.

The machine is compatible with different cable tie styles by replacing the cable tie module

Model	JCW-T08 Fully electric desktop automotive cable tie machine
Cable tie type	Custom
Rated power	100 W
Power supply	AC 110 - 220V ± 10%, 50 / 60 Hz
Dimensions	L 550 x W 350 x H 150 mm
Weight	25 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
