Fully automatic terminal & sleeve processing station
Two sets of crimp presses installed
One set of heat heat-shrinking device installed
Suitable for all types of open barrel terminals
Closed barrel terminals can be custom
JCW-CST18A
Fully automatic terminal & sleeve processing station
Two sets of crimp presses installed
One set of heat heat-shrinking device installed
Suitable for all types of open barrel terminals
Closed barrel terminals can be custom
Dual Crimp Single Shrink
Model | JCW-CST18A Dual-end Crimping Single-end Heat Shrinking Machine |
Function | Single/dual end stripping, Full stripping, Partial stripping Single/Dual end terminal crimping, Single-end heat shrink tubing cutting, insertion & shrink Cut depth, Pull-off length. |
Wire range | AWG 22 - AWG 14 [ 10 AWG on request only ] |
Raw material | PVC, Teflon, Low halogen, etc. |
Crimp force | 2 tons [ 20 KN ] |
Cut length ( L ) | 70 - 99999 mm |
Cut length tolerance | 0.2mm ± 0.002 x L |
Strip length | 1 - 10 mm |
Tubing length | 12 - 30 mm |
Tubing O.D | 2.5 - 7.0 mm |
Production rate | 2000 - 4000 pcs/h by 100mm length |
Detector | Wire lack, Wire knot, Wire stripping, Terminal crimping, Air pressure |
Optional peripherals | CFM, Wire prefeed machine, Motorized conveyor belt |
Display | 7" touch screen, English / Chinese [ other languages on request ] |
Power supply | AC 110 / 220V ± 10%, 50 / 60 Hz |
Rated power | 2800 W |
Air supply | 0.5 - 0.8 MPa [ Clean and dry air ] |
Weight | 700 KG |
Dimensions | L 1060 x W 950 x H 1500 mm |
CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
