High-level 5 Wires Crimping to Tinning Machine

High-level 5 Wires Crimping to Tinning Machine

ModelJCW-CST21 High-end 5 Wires Crimping to Tinning Machine
Wire rangeAWG 32 - AWG 16
Raw material
PVC, Teflon, Low halogen, etc.
Cutting length ( L )42 - 1000 mm [ Other lengths on request ]
Cutting length tolerance0.002 x L
Stripping lengthFront side: Max 9.5 mm [ Customizable ]
Rear side: Max 13.5 mm [ Customizable ]
Twisting length2 - 10.5 mm [ Customizable ]
Tinning length0.5 - 13.5 mm
Production rate5500 - 6500 pcs/h by 300mm cutting length
Data library100 programs
DetectorTerminal run-out, Wire run-out, Wire knot, Terminal crimping, Air pressure, Heating
Optional peripheralsCFM, Wire unwinder, Conveyor belt
Display10" touch screen, English / Chinese  [ other languages on request ]
Power supplyAC 220V ± 10%, 50 / 60 Hz [ 110V on request ]
Rated power2300 W
Air supply0.5 - 0.8 MPa [ Clean and dry air ]
Weight600 KG
DimensionsL 2000 x W 1070 x H 1900 mm
CE-Conformity

Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
