Copper Foil Wrapping Machine for Shielded Cables

JCW-322G

Inquire Now

Shield Cable Wrap Copper Foil

Copper foil wrapping provides excellent electromagnetic interference (EMI) and radio frequency interference (RFI) shielding for cables. It is highly effective for audio interconnects and power cords, though it can make cables stiff and is best suited for stationary installations rather than highly flexible, portable applications.

Model	JCW-322G Copper Foil Wrapping Machine for Shielded Cables
Cable O.D	Max 8 mm [ Change the fixture according to the cable diameter ]
Jacket pre-strip	Min. 40 mm
Foil width	10 mm [ Change the fixture according to the foil width ]
Foil length	20 - 50 mm
Product rate	1000 - 1200 / h
Utilization rate	90 %
Yield rate	98 %
Rated power	500 W
Power supply	AC 110 - 220 V ± 10%, 50 / 60 Hz
Compressed air	0.4 - 0.6 MPa [ Clean and dry ]
Dimensions	L 500 x W 345 x H 440 mm
Weight	35 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
