Wire and Cable Coiling Bundling Machine

JCW-WB05C

Compact, free-standing, fully-programmable and mobile device

Wind the required length of electrical, optical cables or other similar materials

Automatic cable laying device synchronized with rotational motion

Operation without constant, direct supervision

Precise feeding, uniform laying

Inquire Now

Add To Cart

Model	JCW-WB05C Wire and Cable Coiling Bundling Machine
Function	Measure cable, feeding length, laying cable, automatic cut cable, twist cable tie. Feeding speed, winding speed, winding cycles, twisting cycles, cable tie cut length.
Wire diameter	φ 1 - 15 mm [ Customizable ]
Cable tie length	200 - 300 mm [ Customizable]
Tying diameter	40-80 mm [ Optional 8-30 mm / 18 - 45 mm ]
Cable roll inner diameter	50 - 300 mm
Winding speed	1 - 10 cycles / s
Cable tie twist cycle time	0.6 S
Cable weight	3 KG [ Customizable to 50KG ]
Data library	100 programs
Display	7" color touchscreen, English / Chinese [ other languages on request ]
Compatible peripherals	Cable prefeeding machine
Power supply	AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply	0.4 - 0.7 MPa ( clean and dry air )
Dimensions	L 1000 x W 610 x H 1100 mm
Weight	150 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
