Wire & Cable Mid-cut Machine

Wire & Cable Mid-cut Machine

Model

JCW-CS06W Automatic Middle Splitting Cable Window Stripping Machine

Function

Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Split length, Cut depth, Wire run-out sensor, Length correction

Raw materialPVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Conductor cross-sections0.1 - 16 mm², 10 mm diameter
Cutting length ( L )0.1 - 999999 mm
Cutting length accuracy
0.002 x L
Stripping lengthFront ( right ) side: 150 mm [ partial stripping ]
Rear ( left ) side: 70 mm [ partial stripping ]
Production rate600 -1000 pcs/h, depends on the setting.
Data library100 programs
Display4.3" color touchscreen, English / Chinese  [ other languages on request ]
Cable feeding
6 rollers
Compatible peripheralsCable prefeeding unit, robot arm, cable stacker
Power supply
AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply0.4 - 0.7 MPa ( clean and dry air )
DimensionsMachine: L 560 x W 470 x H 370 mm
Cable slitter & straightener: 470mm
Weight55 KG
CE-Conformity

Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
