Small wires AWG 18 - AWG 26
Max 10 KG wire roll
Smooth acceleration & deceleration
Two-way drive, clockwise & anti-clock
Automatic induction with independent brakes
JCW-WP04 10KG Load Motorized Cable Unwinder
Useful wire prefeeder, ultra-cheap
The JCW-WP04 motorized cable unwinder is a useful wire dereeler for small wires ranging from AWG 18 to AWG 26, this lightweight equipment is ideal for tension-free prefeeding to an automatic wire and cable processing machine.
This cable dereeler is equipped with a two-way drive, which is activated with a rotation dancer pendulum arm, the feed speed automatically adjusts to the actual requirement of any wire and cable processing machine, including the cutting machine, cutting and stripping machine, automatic terminal crimping machine, etc.
When ordering wire prefeeding machines, we recommend customers submit cable samples or images, also the cutting length and wire processing machine models, so as to offer the most proper models to meet your processing needs.
JCW-WP04 Economic Motorized Cable Unwinder
|Wire range||AWG 18 - AWG 26|
|Wire roll weight||10 KG|
|Power supply||AC 110 - 220V, 50 / 60 Hz|
|Dimensions||L 390 x W 390 x H 500 mm|
Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
